Product Name Gantry Machining Center
Model Lm3020
Keywords Gantry Machining Center
The X/Y/Z Axis Travel 3000/2000/900 mm
Motor Power of X/Y/Z 5.4/5.4/5.4 Kw
Movement Speed of X/Y/Z 12/12/10 M/Min
Distance(Nose to Workbench) 150-900 mm
Speed of Spindle 6000-8000 Rpm
Taper of Spindle Bt50
Transmission of Spindle Belt Type
Size of Workbench 3000*1700 mm
Max.Capacity of Workbench 6000 Kg
T-Slot Size 22t*9*200
Accuracy of X/Y/Z Position 0.01/300 mm
Accuracy of X/Y/Z Repeat 0.008/300 mm
Transport Package Customized
Specification Customized
Trademark JTC TOOL
Origin Guangdong, China
Production Capacity 10000set/Month
Product Description
DONGGUAN JTC TOOL CO., LTD.JTC TOOL Best Cnc Machining Centers ODM Custom Cnc Milling And Turning China 5 Axis Gantry Type Machining Center Manufacturer LM3020 Cnc Machine Center

Product Description

The Gantry Machining Center Refers To The Machining Center Where The Axis Of The Z Axis Of The Main Shaft Is Perpendicular To The Workbench. The Overall Structure Is A Large Machining Center With A Portal Structure Frame Composed Of Double Columns And Top Beams. There Is A Beam In The Middle Of The Double Columns. Especially Suitable For Processing Large Workpieces And Workpieces With Complex Shapes.The Structural Features Of The Gantry Machining Center Are As Follows:1. The Gantry Is Composed Of A Beam And Two Columns. It Can Be Divided Into Three Types: Beam Fixed, Beam Locked By Positioning Block And Segmented Lifting, And Beam Lifted And Lowered Arbitrarily.2. Ram. The Ram Can Be Divided Into Open Type And Closed Type From The Structure. The Ram Of The Open Structure Is Clamped On The Headstock By The Pressure Plate, And The Cross-Sectional Area Of The Ram Is Large; the Ram Of The Closed Structure IsClamped In The Headstock, The Cross-Sectional Area Of The Ram Is Small.3. Tool Magazine. There Are Three Basic Types Of Tool Magazines: Turret Type, Drum Type, And Chain Length Type.4. Attachment Header Library. The Machining Of Large And Complex Parts Often Requires Many Attachment Heads. The Accessory Head Is Specially Designed According To The Processing Requirements Of The Workpiece, Generally Divided Into a Right-Angle Head, Extended Head, SpecialAngle Head And Universal Head Etc.5. Numerical Control System. Now There Are Many CNC System Suppliers, And There Are Different Choices Of System Brands And Models According To Different Needs.6. Accuracy. The Accuracy Of The Machine Tool Refers To The Original Accuracy Of The Machine Tool Under The Condition Of No External Load. Accuracy Is Usually Expressed By The Deviation Between Its Opposite And The Ideal State, The Smaller The Error, The Higher The Accuracy.AdvantagesCNC Gantry Type Milling Machine Can Accurately Calculate The Working Hours Of Parts Processing, And Effectively Simplify The Management Of Inspection Tools And Semi-Finished Products, Which Is Conductive To The Modernization Of Production Management

Jtc Tool Best CNC Machining Centers ODM Custom CNC Milling and Turning China 5 Axis Gantry Type Machining Center Manufacturer Lm3020 CNC Machine Center

Jtc Tool Best CNC Machining Centers ODM Custom CNC Milling and Turning China 5 Axis Gantry Type Machining Center Manufacturer Lm3020 CNC Machine Center

Jtc Tool Best CNC Machining Centers ODM Custom CNC Milling and Turning China 5 Axis Gantry Type Machining Center Manufacturer Lm3020 CNC Machine Center

Jtc Tool Best CNC Machining Centers ODM Custom CNC Milling and Turning China 5 Axis Gantry Type Machining Center Manufacturer Lm3020 CNC Machine Center

Product Parameters

LM3020 SPECIFICATION

CNC SPEC.

DESCRIPTION

SPECIFICATION

UNIT

X/Y/Z Axis

The X/Y/Z Axis Travel
3000/2000/900MM

Motor Power Of X/Y/Z
5.4/5.4/5.4KW

Movement Speed Of X/Y/Z
12/12/10M/MIN

Spindle

Distance(Nose to Workbench)
150~900MM

Motor Power Of Spindle
17.5KW

Speed Of Spindle
6000-8000RPM

Taper Of Spindle
BT50

Transmission Of Spindle
Belt type

Workbench

Size Of Workbench
3000*1700MM

Max.Capacity of Workbench
6000kg

T-Slot Size
22T*9*200

Tool Magazine

Capacity Of Tool Magazine
24PCS

Max. Weight Of Tool
15KG

Max.Length Of Tool
∅350MM

Max. Diameter Of Tool
∅200MM

Tools Exchange
2.4S

Accurancy

Accuracy Of X/Y/Z Position
±0.01/300MM

Accuracy Of X/Y/Z Repeat
±0.008/300MM
Other
Feed
1-6000MM/MIN

Capacity Of Cooling Tank
L

Air Pressure
6-8Bar

Measurement(L*W*H)
MM

Weight
KG
